Parameter Details
12
12.10 o: KEYPAD
SIEPCYEUOQ2V01A Q2V Technical Manual 697
■ o1-05: LCD Contrast Adjustment
No.
(Hex.)
Name Description
Default
(Range)
o1-05
(0504)
RUN
LCD Contrast Adjustment
Sets the contrast of the LCD display on the keypad.
5
(0 - 10)
When you decrease the setting value, the contrast of the LCD display decreases. When you increase the setting
value, the contrast increases.
■ o1-10: FrqDisplay Max Value
No.
(Hex.)
Name Description
Default
(Range)
o1-10
(0520)
FrqDisplay Max Value
Sets the value that the drive shows as the maximum output frequency.
Determined by o1-03
(1 - 60000)
To display a maximum output frequency of 100.00, set parameters to these values:
• o1-10 = 10000
• o1-11 = 2 [FrqDisplay Decimal Places = (XXX.XX) 2 Decimal Places]
Note:
Set o1-03 = 3 [FrqDisplay Unit Selection = User-selected units] before you set o1-10 and o1-11.
■ o1-11: FrqDisplay Decimal Places
No.
(Hex.)
Name Description
Default
(Range)
o1-11
(0521)
FrqDisplay Decimal Places
Sets the number of decimal places for frequency reference and monitor values.
Determined by o1-03
(0 - 3)
0 : (XXXXX) No Decimal Places
1 : (XXXX.X) 1 Decimal Place
2 : (XXX.XX) 2 Decimal Places
3 : (XX.XXX) 3 Decimal Places
Note:
Set o1-03 = 3 [FrqDisplay Unit Selection = User-selected units] before you set o1-10 [FrqDisplay Max Value] and o1-11.
■ o1-24 to o1-35: Cust.Monitor 1 to 12
No.
(Hex.)
Name Description
Default
(Range)
o1-24 to o1-35:
(11AD - 11B8)
RUN
Cust.Monitor 1 to 12
Sets a maximum of 12 monitors as user monitors. This parameter is only available when using an
LCD keypad.
o1-24: 101
o1-25: 102
o1-26: 103
o1-27 to o1-35: 0
(0, 101 - 999)
These parameters save the monitor items selected by the LCD keypad [Custom Monitor].
Note:
• You can show a maximum of three selected monitors on one LCD keypad screen.
–When you select only one monitor, the text size of this monitor increases. For example, when o1-25 to o1-35 = 0, the text size of the
monitor saved in o1-24 increases.
–When you select two monitors, the text size of these monitors increase.
–When you select four or more monitors, the fourth monitor and all additional monitors are shown on the next screens.
• Monitors selected with o1-24 to o1-26 can be displayed as a bar graph, analog gauge, or trend plot.
–Bar graph display: 3 monitors maximum
Select with o1-24, o1-25, and o1-26.
–Analog gauge display: 1 monitor
Select with o1-24.
–Trend plot display: 2 monitors
Select with o1-24 and o1-25.
• You can only set parameters o1-24 to o1-26 with analog output monitors.
• You can set all monitors to parameters o1-27 to o1-35.
