Parameter Details
12
12.11 T: AUTOTUNING
SIEPCYEUOQ2V01A Q2V Technical Manual 719
■ T2-05: PMMot Rated Voltage
No.
(Hex.)
Name Description
Default
(Range)
T2-05
(0732)
PMMot Rated Voltage
Sets the rated voltage (V) of the motor.
200 V Class: 200.0 V, 400
V: 400.0 V
(200 V Class: 0.0 - 255.0 V,
400 V Class: 0.0 - 510.0 V)
■ T2-06: PMMot Rated Current
No.
(Hex.)
Name Description
Default
(Range)
T2-06
(0733)
PMMot Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04
(10% to 200% of the drive
rated current)
■ T2-07: PMMot Base Frequency
No.
(Hex.)
Name Description
Default
(Range)
T2-07
(0753)
PMMot Base Frequency
Sets the base frequency (Hz) of the motor.
87.5 Hz
(0.0 - 590.0 Hz)
■ T2-08: PMMot Poles Number
No.
(Hex.)
Name Description
Default
(Range)
T2-08
(0734)
PMMot Poles Number
Sets the number of motor poles.
6
(2 - 48)
■ T2-09: PMMot Base Speed
No.
(Hex.)
Name Description
Default
(Range)
T2-09
(0731)
PMMot Base Speed
Sets the motor base speed (min
-1
(r/min)).
1750 min
-1
(r/min)
(0 - 34500 min
-1
(r/min))
■ T2-10: PMMot Stator Resistance
No.
(Hex.)
Name Description
Default
(Range)
T2-10
(0754)
PMMot Stator Resistance
Sets the stator resistance for each motor phase.
Determined by T2-02
(0.000 - 65.000 Ω)
Note:
This parameter does not set line-to-line resistance.
■ T2-11: PMMot dAxis Inductance
No.
(Hex.)
Name Description
Default
(Range)
T2-11
(0735)
PMMot dAxis Inductance
Sets the d-axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
■ T2-12: PMMot qAxis Inductance
No.
(Hex.)
Name Description
Default
(Range)
T2-12
(0736)
PMMot qAxis Inductance
Sets the q-Axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
■ T2-13: KE Unit Selection
No.
(Hex.)
Name Description
Default
(Range)
T2-13
(0755)
KE Unit Selection
Sets the units that the drive uses to set the induced voltage constant.
1
(0, 1)
