12.11 T: AUTOTUNING
SIEPCYEUOQ2V01A Q2V Technical Manual 721
1 : Static R Autotune
■ T4-02: Motor Type Selection
No.
(Hex.)
Name Description
Default
(Range)
T4-02
(3131)
Motor Type Selection
Sets the type of motor.
0
(0, 1, 2)
0 : IM
Induction Motor
1 : PM
Permanent Magnet Motor
2 : SynRM
Synchronous Reluctance Motor
■ T4-04: Motor Rated Revolutions
No.
(Hex.)
Name Description
Default
(Range)
T4-04
(3133)
Motor Rated Revolutions
Sets rated rotation speed (min
-1
) of the motor.
-
((40 Hz to 120 Hz) × 60 ×
2/E9-08)
■ T4-05: Motor Rated Frequency
No.
(Hex.)
Name Description
Default
(Range)
T4-05
(3134)
Motor Rated Frequency
Sets the rated frequency (Hz) of the motor.
Determined by E9-01 and
o2-04
(40.0 - 120.0 Hz)
Note:
When T4-02 = 1, 2 [Motor Type Selection = PM, SynRM], input is not necessary because it assumes: Motor Rated Revolutions/60 ×
Number of Motor Poles/2.
■ T4-06: Motor Rated Voltage
No.
(Hex.)
Name Description
Default
(Range)
T4-06
(3135)
Motor Rated Voltage
Sets the rated voltage (V) of the motor.
200 V Class: 200.0 V, 400
V: 400.0 V
(200 V Class: 0.0 - 255.0
V,400 V Class: 0.0 - 510.0
V)
■ T4-07: Motor Rated Current
No.
(Hex.)
Name Description
Default
(Range)
T4-07
(3136)
Motor Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04, C6-
01
(10% to 200% of the drive
rated current)
Note:
The value set here becomes the base value for motor protection, the torque limit, and torque control.
■ T4-08: Motor Rated Capacity
No.
(Hex.)
Name Description
Default
(Range)
T4-08
(3137)
Motor Rated Capacity
Sets the motor rated power in the units set in o1-58 [Mot Capacity Unit].
Determined by E9-10
(0.10 - 650.00 kW)
