High-function General-purpose Inverter RX2 Series User’s Manual
Install the PG Option Unit to SLOT 2 in the inverter’s Cassette Option Connection.
Precautions for Correct Use
If you install PG Option Unit to SLOT1, the inverter cannot be operated due to the power dis-
connection.
If you install PG Option Unit to SLOT3, the inverter and PG Option unit may result in damage
due to connector’s interference.
(a) Remove the cover on the Cassette Option Connection of the main body. The cover is not needed
any more but it must be retained because it may be needed in case you operate the inverter tempo-
rarily when option unit fails. The screws which had fixed the cover are needed for fixing the PG
Option Unit.
Specifications
Item Specifications
Model 3G3AX-RX2-PG01
Dimensions
(width × height × depth)
20.5×98.0×70.0 mm
Weight 170 g
Environment
Ambient operating
temperature
-10 to 50°C
With no icing or condensation
Ambient operating
humidity
20 to 90% RH
Storage temperature
*1
*1. The storage temperature is the temperature during transportation.
-20 to 65°C
Vibration resistance
5.9 m/s
2
(0.6G), 10 to 55 Hz
Protective structure IP00
Encoder feedback
• Standard encoder pulse number: 1024 pulse/r
• Max. input pulse number: 200k pulse/s
Position command Max. input pulse number: 200k pulse/s
Protection function
• Encoder cable breakage protection
• RX2-PG Connection Error
PG Option Unit mounting
USB(micro-B)
RJ45
SLOT1
SLOT2 SLOT3
Cassette Option Connection
LCD Operator
Unscrew to remove the
cover. Those screws are
needed later.
To Next Page
