3 Operation
3 - 42
High-function General-purpose Inverter RX2 Series User’s Manual
(t) PID 3
Diplay condition: AJ – 21 = 01, 02
(u) PID 4
Display condition: AJ – 41 = 01, 02
AJ-06 PID2 scale adjustment (decimal point)
AJ-07 PID2 target value Input destination selection
AJ-10 PID2 target value Set value
AJ-12 PID2 feedback data Input destination selection
AJ-13 PID2 proportional gain
AJ-14 PID2 integral gain
AJ-15 PID2 differential gain
AJ-16 PID2 changeable range
AJ-17 PID2 excessive deviation level
AJ-18 PID2 feedback comparison signal OFF level
AJ-19 PID2 feedback comparison signal ON level
Parameter Name
db-38 PID3 feedback data monitor
db-57 PID3 output monitor
db-58 PID3 deviation monitor
FA-38 PID3 target value (monitor + setting)
AJ-22 PID3 deviation minus
AJ-23 PID3 unit selection (PID3)
AJ-24 PID3 scale adjustment (0%)
AJ-25 PID3 scale adjustment (100%)
AJ-26 PID3 scale adjustment (decimal point)
AJ-27 PID3 target value Input destination selection
AJ-30 PID3 target value setting
AJ-32 PID3 feedback data Input destination selection
AJ-33 PID3 proportional gain
AJ-34 PID3 integral gain
AJ-35 PID3 differential gain
AJ-36 PID3 changeable range
AJ-37 PID3 excessive deviation level
AJ-38 PID3 feedback comparison signal OFF level
AJ-39 PID3 feedback comparison signal ON level
Parameter Name
db-40 PID4 feedback data monitor
db-59 PID4 output monitor
db-60 PID4 deviation monitor
FA-40 PID4 target value (monitor + setting)
AJ-42 PID4 deviation minus
AJ-43 PID4 unit selection (PID4)
AJ-44 PID4 scale adjustment (0%)
AJ-45 PID4 scale adjustment (100%)
AJ-46 PID4 scale adjustment (decimal point)
AJ-47 PID4 target value Input destination selection
AJ-50 PID4 target value setting
AJ-52 PID4 feedback data Input destination selection
AJ-53 PID4 proportional gain
Parameter Name
