3 Operation
3 - 62
High-function General-purpose Inverter RX2 Series User’s Manual
Open the Monitor folder in the project and double-click Real Time Trace.
The Real Time Trance window opens, in which you can monitor the operation status of the inverter.
• Up to 8 signals can be traced.
• Triggers can be set to the ON/OFF timing of the inverter’s internal status, or numerically.
Monitor Function of CX-Drive
To Next Page
