Omron RX2 Series User Manual

7 - 9
7 Advanced Settings
High-function General-purpose Inverter RX2 Series User’s Manual
7-2 Selection of Motor Control Methods
7
7-2-3 V/f Control (Free V/f)
 Parameter
Item Parameter Data Description
Default
data
Control mode
selection,
1st-motor
[AA121] 02: Free V/f (IM) To use the free V/f (IM) 00
Stabilization con-
stant, 1st-motor
[HA110] 0 to 1000(%)
To adjust the control for reducing the
hunting of motors.
100
Async.Motor Base
frequency setting,
1st-motor
[Hb104]
10.00 to the maximum fre-
quency (Hz)
To set the base frequency of motors.
50
*1
*1. Default data when default data selection (UB-02) is set to 01.
Async.Motor Maxi-
mum frequency
setting, 1st-motor
[Hb105]
Base frequency to 590.00
(Hz)
To set the maximum frequency of
motors.
50
*1
Async.Motor rated
voltage, 1st-motor
[Hb106] 1 to 1000 (V) Set the rated voltage of motors.
200V:
230
*1
400V:
400
*1
Free-V/f frequency
7 setting, 1st-motor
[Hb162]
[Hb160] to the base fre-
quency (Hz)
Set the frequency at each break
point.
0.00
Free-V/f frequency
6 setting, 1st-motor
[Hb160] [Hb158] to [Hb162] (Hz)
Free-V/f frequency
5 setting, 1st-motor
[Hb158] [Hb156] to [Hb160] (Hz)
Free-V/f frequency
4 setting, 1st-motor
[Hb156] [Hb154] to [Hb158] (Hz)
Free-V/f frequency
3 setting, 1st-motor
[Hb154] [Hb152] to [Hb156] (Hz)
Free-V/f frequency
2 setting, 1st-motor
[Hb152] [Hb150] to [Hb154] (Hz)
Free-V/f frequency
1 setting, 1st-motor
[Hb150] 0.00 to [H152](Hz)
Free-V/f Voltage 7
setting, 1st-motor
[Hb163]
0.0 to 1000.0(V)
Set the output voltage at each break
point.
0.0
Free-V/f Voltage 6
setting, 1st-motor
[Hb161]
Free-V/f Voltage 5
setting, 1st-motor
[Hb159]
Free-V/f Voltage 4
setting, 1st-motor
[Hb157]
Free-V/f Voltage 3
setting, 1st-motor
[Hb155]
Free-V/f Voltage 2
setting, 1st-motor
[Hb153]
Free-V/f Voltage 1
setting, 1st-motor
[Hb151]
