7 - 23
7 Advanced Settings
High-function General-purpose Inverter RX2 Series User’s Manual
7-2 Selection of Motor Control Methods
7
7-2-11 Synchronous Motor (Permanent Magnet Motor) Control
The following functions cannot be used when the synchronous motor (permanent magnet motor) con-
trol is conducted.
Even when they are enabled by parameters of setting, they are actually disabled.
In the following table, only the common settings (parameter center “-”) and the first settings (parameter
center “1”) are listed, but it is not possible either to use the second settings (parameter center “2”) that
correspond to the first settings in the following table.
Disabled Functions
Item Parameter Description
Functions associated with
torque control
[FA-15], [FA-16], [dA-15], and [dA-16]
Torque command monitoring
function
[Ad-01] to [Ad-04], and [Ad-40] to [Ad-43], Input
terminal 067 [ATR]
Torque controlling function
[Ad-11] to [Ad-14], Input terminal 068 [TBS] Torque biasing function
[bA110] to [bA116], and [bA210] to [bA216],
Input terminals 060 [TL], 061 [TRQ1], and 062
[TRQ2]
Output terminal 022 [TRQ]
Torque limiting function
[CE120] to [CE123], Output terminal 019 [OTQ] Over torque signal
Over current restraining
function
[bA120] and [bA121] Over current restraining function
Functions associated with
induction motor control
[HA110] Stabilization adjustment gain
[Hb130], [Hb131], [Hb140] to [Hb142], [Hb145],
[Hb146], [Hb150] to [Hb163], [Hb170], [Hb171],
and [Hb180]
Functions associated with V/f
control
[HC101] and [HC102]
Functions associated with auto-
matic boost
[HC110] to [HC114], [HC120], and [HC121]
Sensorless vector control,
Zero-speed range sensorless
vector control
Part of gain mapping func-
tion
[HA126],[HA129] Constant for I control
Part of auto-tuning
[HA-01]=02 Rotating system tuning
[HA-03] Online auto-tuning
Commercial power supply
switching function
Input terminal 035 [CS]
Switching to commercial power
supply
Acceleration or decelera-
tion cancellation function
Input terminal 071 [LAC]
Acceleration or deceleration can-
cellation function
Jogging operation [AG-20], [AG-21], input terminal 029 [JG] Jogging operation function
