Omron RX2 Series User Manual

7 - 55
7 Advanced Settings
High-function General-purpose Inverter RX2 Series User’s Manual
7-3 Torque Control
7
7-3-6 Torque Bias Function
Commanded torque bias value can be monitored on the [FA-16] torque bias monitor.
In the case of [Ad-11] = 07, the setting can be changed on the [FA-16] monitor.
The torque command monitor (after calculation) [dA-15] displays the value with torque bias added to
the current torque command.
To calculate the motor rated torque (100%) in this function, use the following formula.
Motor rated torque = 79.58 × Motor capacity × Number of poles/Base frequency
Example: Motor rated torque = 79.58 × 5.5 (kW) × 4 (P)/50 (Hz) ≈ 35 Nm
 Parameter
Torque Bias Command Value Monitor
Item Parameter Data Description
Default
data
Torque bias input
source selection
[Ad-11] 00 to 13,15
00 (Disable)/01 (Ai1 terminal input)/
02 (Ai2 terminal input)/ 03 (Ai3 terminal input)/
04 (Reserved)/05 (Reserved)/06 (Reserved)/
07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/ 11 (Option 3)/
12 (Pulse train input: main unit)/
13 (Pulse train input: Option)/
15 (PID calculation)
00
Torque bias value
setting
[Ad-12]
-500.0 to
500.0(%)
Adds a torque addition amount. 0.0
Polarity selection
for torque bias
[Ad-13]
00 (Per sign)
Regardless of the operation direction, torque
will be added to the forward direction, when the
value is (+), and to the reverse direction, when
the the value is (-).
00
01 (Follow the
revolution
direction)
Torque bias [Ad-12] is applied to the operation
direction when (+), and applied to the reverse
direction when (-).
Terminal [TBS]
active
[Ad-14]
00 Disable
00
01 Enable
Torque bias moni-
tor
[FA-16]
-500.00 to
500.00(%)
Is the torque bias set monitor. -
Torque command
monitor after calcu-
lation
[dA-15]
-500.00 to
500.00(%)
Is the torque command monitor calculated set
value and bias value.
-
Input terminal func-
tion
[CA-01] to
[CA-11]
068
[TBS]: Can switch enable/disable of bias by the
terminal ON/OFF switch when [TBS] is
assigned and [Ad-11] = 01.
ON: Enable/OFF: Disable
-
