8-2 Tripless Functions
8
8-2-4 Overexcitation Function
Activated when the P-N voltage exceeds the set level
Activated when the P-N voltage exceeds the set level only during deceleration
For Level Operation [bA146] = 03
For Level Operation during Deceleration [bA146] = 04
[bA147 ]=0.0
[bA148 ]
[bA146 ]=00
Main Circuit DC Section
P-N Voltage (Vdc)
Output Voltage (V)
Time
Time
High
Low
[bA147] Set
Overexcitation
Suppression Level
[bA149]
[bA147 ]=0.0
[bA148 ]
[bA146 ]=00
Main Circuit DC Section
P-N Voltage (Vdc)
Output Voltage (V)
Time
Time
High
Low
[bA147] Set
Overexcitation Sup-
pression Level
[bA149]
Deceleration
Starts
No Response
Set Deceleration
Time
