8 - 67
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-2 Tripless Functions
8
8-2-8 Non-stop on Momentary Power Interruption
(Ex.1)
Note Depending on the proportional gain and integral time settings, the main circuit DC voltage level while the
function is being activated may be lower than [bA-32].
(Ex.2)
[bA-32]
[bA-
31]
ON
Time
Time (sec)
Time
Main Circuit P-N Voltage (V)
Power recovered
Main Circuit DC
Voltage
Under Constant DC Voltage Control
[bA-30] = 02 or 03
(Deceleration and stop)
Power Recovery
[IPS] Signal
[bA-32]
[bA-31]
ON
Time
Time
Main Circuit P-N Voltage (V)
Power recovered
Main Circuit DC Voltage
Under Constant DC
Voltage Control
[bA-30] = 02
(Deceleration and stop)
Power
Recovery
[IPS] Signal
[bA-30] = 03 (Operation)
