The operations of 16C are as follows.
The specifications of the relay contact 16C are as follows.
 Parameter
Contact a:
The contact closes when the functional operation is ON and opens when OFF.
Contact b:
The contact closes when the functional operation is OFF and opens when ON.
Relay Output 16C
[CC-16] Control power Functional operation Output terminal state
00
On
ON Close
OFF Open
Off - Open
01
On
ON Open
OFF Close
Off - Open
Resistive load Inductive load
16C
Maximum contact capacity AC250V,2A AC250V,1A
Minimum contact capacity AC250V,1mA
Item Parameter Data Description
Output terminal func-
tion selection 11-15
[CC-01] to
[CC-05]
017
An alarm signal is output to the output terminal to
which 017 [AL] has been assigned.
ON: When an alarm has occurred
OFF: When no alarm has occurred
Relay output terminal
function selection
16A-16C
[CC-06]
Relay output terminal
function selection
AL1-AL0/AL2-AL0
[CC-07]
Output terminal func-
tion selection
[CC-11] to
[CC-15]
00 Operates as contact a (NO).
01 Operates as contact b (NC).
1a relay output termi-
nal function selection
a/b (NO/NC) selection
[CC-16]
00 Operates as contact a (NO).
01 Operates as contact b (NC).
1c relay output termi-
nal function selection
a/b (NO/NC) selection
[CC-17]
00
See the table at the upper left.
01
