9 Communications Functions
9 - 44
High-function General-purpose Inverter RX2 Series User’s Manual
2F4Fh 2F4Eh Multispeed-1 setting Ab-11 R/W 0 to 59000 0.01(Hz)
2F50h 2F4Fh Multispeed-2 setting Ab-12 R/W 0 to 59000 0.01(Hz)
2F51h 2F50h Multispeed-3 setting Ab-13 R/W 0 to 59000 0.01(Hz)
2F52h 2F51h Multispeed-4 setting Ab-14 R/W 0 to 59000 0.01(Hz)
2F53h 2F52h Multispeed-5 setting Ab-15 R/W 0 to 59000 0.01(Hz)
2F54h 2F53h Multispeed-6 setting Ab-16 R/W 0 to 59000 0.01(Hz)
2F55h 2F54h Multispeed-7 setting Ab-17 R/W 0 to 59000 0.01(Hz)
2F56h 2F55h Multispeed-8 setting Ab-18 R/W 0 to 59000 0.01(Hz)
2F57h 2F56h Multispeed-9 setting Ab-19 R/W 0 to 59000 0.01(Hz)
2F58h 2F57h Multispeed-10 setting Ab-20 R/W 0 to 59000 0.01(Hz)
2F59h 2F58h Multispeed-11 setting Ab-21 R/W 0 to 59000 0.01(Hz)
2F5Ah 2F59h Multispeed-12 setting Ab-22 R/W 0 to 59000 0.01(Hz)
2F5Bh 2F5Ah Multispeed-13 setting Ab-23 R/W 0 to 59000 0.01(Hz)
2F5Ch 2F5Bh Multispeed-14 setting Ab-24 R/W 0 to 59000 0.01(Hz)
2F5Dh 2F5Ch Multispeed-15 setting Ab-25 R/W 0 to 59000 0.01(Hz)
2FA9h 2FA8h
Acceleration/ Deceleration
Time input selection
AC-01 R/W
00: Parameter setting
01: Option 1
02: Option 2
03: Option 3
04: DriveProgramming
-
2FAAh 2FA9h
Acceleration/ Deceleration
Selection
AC-02 R/W
00: Common
01: Multi-stage accelera-
tion/deceleration
-
2FABh 2FAAh Acceleration curve selection AC-03 R/W
00: Linear
01: S-shaped
02: U-shaped
03: Reverse U-shaped
04: Elevator S-shaped
-
2FACh 2FABh Deceleration curve selection AC-04 R/W
00: Linear
01: S-shaped
02: U-shaped
03: Reverse U-shaped
04: Elevator S-shaped
-
2FADh 2FACh
Acceleration curve constant
setting
AC-05 R/W 1 to 10 1
2FAEh 2FADh
Deceleration curve constant
setting
AC-06 R/W 1 to 10 1
2FB0h 2FAFh
EL-S-curve ratio @start of
acceleration
AC-08 R/W 0 to 100 1(%)
2FB1h 2FB0h
EL-S-curve ratio @end of
acceleration
AC-09 R/W 0 to 100 1(%)
2FB2h 2FB1h
EL-S-curve ratio @start of
deceleration
AC-10 R/W 0 to 100 1(%)
2FB3h 2FB2h
EL-S-curve ratio @end of
deceleration
AC-11 R/W 0 to 100 1(%)
2FB7h 2FB6h
Select method to switch to
Accel2/Decel2 Profile,
1st-motor
AC115 R/W
00: [2CH] terminal
01: Parameter setting
02: Switching normal/reverse
rotation
-
2FB8h 2FB7h
Accel1 to Accel2 Frequency
transition point, 1st-motor
AC116 R/W 0 to 59000 0.01(Hz)
2FB9h 2FB8h
Decel1 to Decel2 Frequency
transition point, 1st-motor
AC117 R/W 0 to 59000 0.01(Hz)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
