9 Communications Functions
9 - 62
High-function General-purpose Inverter RX2 Series User’s Manual
56CCh 56CBh
Acceleration time setting 1,
2nd-motor
AC220
(HIGH)
R/W
same as AC120 0.01(s)
56CDh 56CCh
AC221
(LOW)
R/W
56Ceh 56CDh
Deceleration time setting 1,
2nd-motor
AC222
(HIGH)
R/W
same as AC122 0.01(s)
56CFh 56Ceh
AC223
(LOW)
R/W
56D0h 56CFh
Acceleration time setting 2,
2nd-motor
AC224
(HIGH)
R/W
same as AC124 0.01(s)
56D1h 56D0h
AC225
(LOW)
R/W
56D2h 56D1h
Deceleration time setting 2,
2nd-motor
AC226
(HIGH)
R/W
same as AC126 0.01(s)
56D3h 56D2h
AC227
(LOW)
R/W
57E5h 57E4h
DC braking selection,
2nd-motor
AF201 R/W same as AF101 -
57E6h 57E5h
Braking type selection,
2nd-motor
AF202 R/W same as AF102 -
57E7h 57E6h
DC braking frequency,
2nd-motor
AF203 R/W same as AF103 0.01(Hz)
57E8h 57E7h
DC braking delay time,
2nd-motor
AF204 R/W same as AF104 0.01(s)
57E9h 57E8h
DC braking force setting,
2nd-motor
AF205 R/W same as AF105 1(%)
57Eah 57E9h
DC braking active time at
stop, 2nd-motor
AF206 R/W same as AF106 0.01(s)
57Ebh 57EAh
DC braking operation method
selection, 2nd-motor
AF207 R/W same as AF107 -
57Ech 57EBh
DC braking force at start,
2nd-motor
AF208 R/W same as AF108 1(%)
57Edh 57ECh
DC braking active time at
start, 2nd-motor
AF209 R/W same as AF109 0.01(s)
57F8h 57EDh
ContactorControl Enable,
2nd-motor
AF220 R/W same as AF120 -
57F9h 57F8h Run delay time, 2nd-motor AF221 R/W same as AF121 0.01(s)
57Fah 57F9h
Contactor off delay time,
2nd-motor
AF222 R/W same as AF122 0.01(s)
57FBh 57FAh
Contactor answer back check
time, 2nd-motor
AF223 R/W same as AF123 0.01(s)
5802h 5801h
Brake Control Enable,
2nd-motor
AF230 R/W same as AF130 -
5803h 5802h
Brake Wait Time for Release,
2nd
-mo
tor (Forward side)
AF231 R/W same as AF131 0.01(s)
5804h 5803h
Brake Wait Time for Accel.,
2nd-motor (Forward side)
AF232 R/W same as AF132 0.01(s)
5805h 5804h
Brake Wait Time for Stopping,
2nd-motor (Forward side)
AF233 R/W same as AF133 0.01(s)
5806h 5805h
Brake Wait Time for Confir-
mation, 2nd-motor (Forward
side)
AF234 R/W same as AF134 0.01(s)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
