Omron RX2 Series User Manual

9 Communications Functions
9 - 82
High-function General-purpose Inverter RX2 Series User’s Manual
3AFEh 3AFDh
Async. Motor capacity setting,
1st-motor
Hb102 R/W 1 to 16000 0.01(kW)
3AFFh 3AFEh
Async. Motor poles setting,
1st-motor
Hb103 R/W 2 to 48 (poles) 1
3B00h 3AFFh
Async. Motor Base frequency
setting, 1st-motor
Hb104 R/W 10.00 to 590.00 (Hz) 0.01(Hz)
3B01h 3B00h
Async. Motor Maximum fre-
quency setting, 1st-motor
Hb105 R/W
10.00 to 590.00 (Hz)
0.01(Hz)
3B02h 3B01h
Async. Motor rated voltage,
1st-motor
Hb106 R/W
1 to 1000 (V)
1(V)
3B04h 3B03h
Async. Motor rated current,
1st-motor
Hb108
(HIGH)
R/W
1 to 1000000 0.01(A)
3B05h 3B04h
Hb109
(LOW)
R/W
3B06h 3B05h
Async. Motor constant R1,
1st-motor
Hb110
(HIGH)
R/W
1 to 1000000000
0.000001
(Ω)
3B07h 3B06h
Hb111
(LOW)
R/W
3B08h 3B07h
Async. Motor constant R2,
1st-motor
Hb112
(HIGH)
R/W
1 to 1000000000
0.000001
(Ω)
3B09h 3B08h
Hb113
(LOW)
R/W
3B0Ah 3B09h
Async. Motor constant L,
1st-motor
Hb114
(HIGH)
R/W
1 to 1000000000
0.000001
(mH)
3B0Bh 3B0Ah
Hb115
(LOW)
R/W
3B0Ch 3B0Bh
Async. Motor constant Io,
1st-motor
Hb116
(HIGH)
R/W
1 to 1000000 0.01(A)
3B0Dh 3B0Ch
Hb117
(LOW)
R/W
3B0Eh 3B0Dh
Async. Motor constant J,
1st-motor
Hb118
(HIGH)
R/W
1 to 1000000000
0.00001
(kg·m
2)
3B0Fh 3B0Eh
Hb119
(LOW)
R/W
3B1Ah 3B19h
Minimum frequency adjust-
ment, 1st-motor
Hb130 R/W 10 to 1000 0.01(Hz)
3B1Bh 3B1Ah
Reduced voltage start time
setting, 1st-motor
Hb131 R/W 0 to 2000 1(ms)
3B24h 3B23h
Manual torque boost opera-
tional mode selection,
1st-motor
Hb140 R/W
00: Disabled
01: Always enabled
02: Enabled only for forward rev-
olution
03: Enabled only for reverse rev-
olution
-
3B25h 3B24h
Manual torque boost value,
1st-motor
Hb141 R/W 0 to 200 0.1(%)
3B26h 3B25h
Manual torque boost Peak
speed, 1st-motor
Hb142 R/W 0 to 500 0.1(%)
3B29h 3B28h Eco drive enable, 1st-motor Hb145 R/W
00: Disabled
01: Enabled
-
3B2Ah 3B29h
Eco drive response adjust-
ment, 1st-motor
Hb146 R/W 0 to 100 1(%)
3B2Eh 3B2Dh
Free-V/f frequency 1 setting,
1st-motor
Hb150 R/W 0 to 59000 (Hb152) 0.01(Hz)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
