9 Communications Functions
9 - 84
High-function General-purpose Inverter RX2 Series User’s Manual
3BC7h 3BC6h
Sync. Motor poles setting,
1st-motor
Hd103 R/W 2 to 48 (poles) 1
3BC8h 3BC7h
Sync. Base frequency setting,
1st-motor
Hd104 R/W 1000 to 59000 0.01(Hz)
3BC9h 3BC8h
Sync. Maximum frequency
setting, 1st-motor
Hd105 R/W 1000 to 59000 0.01(Hz)
3BCAh 3BC9h
Sync. Motor rated voltage,
1st-motor
Hd106 R/W 1 to 1000 1(V)
3BCCh 3BCBh
Sync. Motor rated current,
1st-motor
Hd108
(HIGH)
R/W
1 to 1000000 0.01(A)
3BCDh 3BCCh
Hd109
(LOW)
R/W
3BCEh 3BCDh
Sync. Motor constant R,
1st-motor
Hd110
(HIGH)
R/W
1 to 1000000000
0.000001
(Ω)
3BCFh 3BCEh
Hd111
(LOW)
R/W
3BD0h 3BCFh
Sync. Motor constant Ld,
1st-motor
Hd112
(HIGH)
R/W
1 to 1000000000
0.000001
(mH)
3BD1h 3BD0h
Hd113
(LOW)
R/W
3BD2h 3BD1h
Sync. Motor constant Lq,
1st-motor
Hd114
(HIGH)
R/W
1 to 1000000000
0.000001
(mH)
3BD3h 3BD2h
Hd115
(LOW)
R/W
3BD4h 3BD3h
Sync. Motor constant Ke,
1st-motor
Hd116
(HIGH)
R/W
1 to 1000000
0.1m
(Vs/rad)
3BD5h 3BD4h
Hd117
(LOW)
R/W
3BD6h 3BD5h
Sync. Motor constant J,
1st-motor
Hd118
(HIGH)
R/W
1 to 1000000000
0.00001
(kg·m
2)
3BD7h 3BD6h
Hd119
(LOW)
R/W
3BE2h 3BE1h
Minimum Frequency for Sync.
M-SLV, 1st-motor
Hd130 R/W 0 to 50 1(%)
3BE3h 3BE2h
No-Load current for Sync.
M-SLV, 1st-motor
Hd131 R/W 0 to 100 1(%)
3BE4h 3BE3h
Starting Method for Sync. M,
1st-motor
Hd132 R/W
00: Position estimation disabled
01: Position estimation enabled
-
3BE5h 3BE4h
IMPE 0V wait number for
Sync. M, 1st-motor
Hd133 R/W 0 to 255 1
3BE6h 3BE5h
IMPE detect wait number for
Sync. M, 1st-motor
Hd134 R/W 0 to 255 1
3BE7h 3BE6h
IMPE detect number for Sync.
M, 1st-motor
Hd135 R/W 0 to 255 1
3BE8h 3BE7h
IMPE voltage gain for Sync.
M, 1st-motor
Hd136 R/W 0 to 200 1(%)
3BE9h 3BE8h
IMPE Mg-pole position offset,
1st-motor
Hd137 R/W 0 to 359 1(deg)
3BEDh 3BECh Carrier frequency at IVMS Hd-41 R/W 5 to 160 0.01(Hz)
3BEEh 3BEDh
Filter gain of current detection
at IVMS
Hd-42 R/W 0 to 1000 1
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
