9 Communications Functions
9 - 88
High-function General-purpose Inverter RX2 Series User’s Manual
62D6h 62D5h
Sync. Motor capacity setting,
2nd-motor
Hd202 R/W Same as Hd102 0.01(kW)
62D7h 62D6h
Sync. Motor poles setting,
2nd-motor
Hd203 R/W Same as Hd103 1
62D8h 62D7h
Sync. Base frequency setting,
2nd-motor
Hd204 R/W Same as Hd104 0.01(Hz)
62D9h 62D8h
Sync. Maximum frequency
setting, 2nd-motor
Hd205 R/W Same as Hd105 0.01(Hz)
62Dah 62D9h
Sync. Motor rated voltage,
2nd-motor
Hd206 R/W Same as Hd106 1(V)
62DCh 62DBh
Sync. Motor rated current,
2nd-motor
Hd208
(HIGH)
R/W
Same as Hd108 0.01(A)
62DDh 62DCh
Hd209
(LOW)
R/W
62Deh 62DDh
Sync. Motor constant R,
2nd-motor
Hd210
(HIGH)
R/W
Same as Hd110
0.000001
(Ω)
62DFh 62DEh
Hd211
(LOW)
R/W
62E0h 62DFh
Sync. Motor constant Ld,
2nd-motor
Hd212
(HIGH)
R/W
Same as Hd112
0.000001
(mH)
62E1h 62E0h
Hd213
(LOW)
R/W
62E2h 62E1h
Sync. Motor constant Lq,
2nd-motor
Hd214
(HIGH)
R/W
Same as Hd114
0.000001
(mH)
62E3h 62E2h
Hd215
(LOW)
R/W
62E4h 62E3h
Sync. Motor constant Ke,
2nd-motor
Hd216
(HIGH)
R/W
Same as Hd116
0.1m
(Vs/rad)
62E5h 62E4h
Hd217
(LOW)
R/W
62E6h 62E5h
Sync. Motor constant J,
2nd-motor
Hd218
(HIGH)
R/W
Same as Hd118
0.00001
(kg·m
2)
62E7h 62E6h
Hd219
(LOW)
R/W
62F2h 62F1h
Minimum Frequency for Sync.
M-SLV, 2nd-motor
Hd230 R/W Same as Hd130 1(%)
62F3h 62F2h
No-Load current for Sync.
M-SLV, 2nd-motor
Hd231 R/W Same as Hd131 1(%)
62F4h 62F3h
Starting Method for Sync. M,
2nd-motor
Hd232 R/W Same as Hd132 -
62F5h 62F4h
IMPE 0V wait number for
Sync. M, 2nd-motor
Hd233 R/W Same as Hd133 1
62F6h 62F5h
IMPE detect wait number for
Sync. M, 2nd-motor
Hd234 R/W Same as Hd134 1
62F7h 62F6h
IMPE detect number for Sync.
M, 2nd-motor
Hd235 R/W Same as Hd135 1
62F8h 62F7h
IMPE voltage gain for Sync.
M, 2nd-motor
Hd236 R/W Same as Hd136 1(%)
62F9h 62F8h
IMPE Mg-pole position offset,
2nd-motor
Hd237 R/W Same as Hd137 1(deg)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
To Next Page
