9 Communications Functions
9 - 96
High-function General-purpose Inverter RX2 Series User’s Manual
3E8Dh 3E8Ch
run command enable option
during the option card
(SLOT-1) start-up
oA-13 R/W
00: Operation command disabled
01: Operation command enabled
-
3E94h 3E93h
Operation mode on option
card error (SLOT-2)
oA-20 R/W
00: Error
01: Continue operation
-
3E95h 3E94h
Communication Watch Dog
Timer
oA-21 R/W 0 to 10000 0.01(s)
3E96h 3E95h
Action selection at communi-
cation error
oA-22 R/W
00: Error
01: Trip after deceleration stop
02: Ignore
03: Free run
04: Deceleration stop
-
3E97h 3E96h
run command enable option
during the option card
(SLOT-2) start-up
oA-23 R/W
00 (Operation command dis-
abled)/
01 (Operation command enabled)
-
3E9Eh 3E9Dh
Operation mode on option
card error (SLOT-3)
oA-30 R/W
00: Error
01: Continue operation
-
3E9Fh 3E9Eh
Communication Watch Dog
Timer
oA-31 R/W 0 to 10000 0.01(s)
3EA0h 3E9Fh
Action selection at communi-
cation error
oA-32 R/W
00: Error
01: Trip after deceleration stop
02: Ignore
03: Free run
04: Deceleration stop
-
3EA1h 3EA0h
run command enable option
during the option card
(SLOT-3) start-up
oA-33 R/W
00: Operation command disabled
01: Operation command enabled
-
3EE5h 3EE4h Encoder constant setting ob-01 R/W 32 to 65535 1(pls)
3EE6h 3EE5h Encoder position selection ob-02 R/W
00: Phase-A is leading
01: Phase-B is leading
-
3EE7h 3EE6h Motor gear ratio Numerator ob-03 R/W 1 to 10000 1
3EE8h 3EE7h Motor gear ratio Denominator ob-04 R/W 1 to 10000 1
3EEEh 3EEDh
Pulse train detection object
selection
ob-10 R/W
00: Command
01: Pulse string position com-
mand
-
3EEFh 3EEEh
Mode selection of pulse train
input
ob-11 R/W
00: 90° phase difference
01: forward/reverse rotation com-
mand and rotation direction
02: forward/reverse rotation pulse
string
-
3EF0h 3EEFh Pulse train frequency Scale ob-12 R/W 5 to 20000
0.01
(kHz)
3EF1h 3EF0h
Pulse train frequency Filter
time constant
ob-13 R/W 1 to 200 0.01(s)
3EF2h 3EF1h
Pulse train frequency Bias
value
ob-14 R/W -1000 to 1000 0.1(%)
3EF3h 3EF2h
Pulse train frequency High
Limit
ob-15 R/W 0 to 1000 0.1(%)
3EF4h 3EF3h
Pulse train freque
ncy d
etec-
tion low level
ob-16 R/W 0 to 1000 0.1(%)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
To Next Page
