Omron RX2 Series - Page 735

11 - 37
11 Options
High-function General-purpose Inverter RX2 Series User’s Manual
11-7 Input Noise Filter
(Model: 3G3AX-NFI)
11
11-7-2 External Dimensions
3G3AX-NFI21/NFI22
Inverter side
66
52
(10)
L3' L2' L1'
L3 L2 L1
(84)
100
117
Ground terminal
2-φ5.0
10
M4
67 max.
(15)
Power supply
side
