Omron RX2 Series - Page 858

Appendices C Table of Parameters
C - 10
High-function General-purpose Inverter RX2 Series User’s Manual
dE-15
Trip monitor 5 Factor 1 to 255
Trip monitor 5 Output frequency(with sign)(HIGT)
-59000 to 59000
Trip monitor 5 Output frequency(with sign)(LOW)
Trip monitor 5 Output current 0 to 65535
Trip monitor 5 P-N DC voltage 0 to 10000
Trip monitor 5 Inverter state
0 to 8
*1
Trip monitor 5 LAD state
0 to 5
*1
Trip monitor 5 INV control mode
0 to 11
*1
Trip monitor 5 Limit state
0 to 6
*1
Trip monitor 5 Special state
0 to 6
*1
Trip monitor 5 RUN time(HIGH)
0 to 1000000
Trip monitor 5 RUN time(LOW)
Trip monitor 5 Power ON time(HIGH)
0 to 1000000
Trip monitor 5 Power ON time(LOW)
Trip monitor 5 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Trip monitor 5 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Trip monitor 5 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
dE-16
Trip monitor 6 Factor 1 to 255
Trip monitor 6 Output frequency(with sign)(HIGT)
-59000 to 59000
Trip monitor 6 Output frequency(with sign)(LOW)
Trip monitor 6 Output current 0 to 65535
Trip monitor 6 P-N DC voltage 0 to 10000
Trip monitor 6 Inverter state
0 to 8
*1
Trip monitor 6 LAD state
0 to 5
*1
Trip monitor 6 INV control mode
0 to 11
*1
Trip monitor 6 Limit state
0 to 6
*1
Trip monitor 6 Special state
0 to 6
*1
Trip monitor 6 RUN time(HIGH)
0 to 1000000
Trip monitor 6 RUN time(LOW)
Trip monitor 6 Power ON time(HIGH)
0 to 1000000
Trip monitor 6 Power ON time(LOW)
Trip monitor 6 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Trip monitor 6 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Trip monitor 6 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
Code Name Data range
