Omron RX2 Series User Manual

Appendices C Table of Parameters
C - 16
High-function General-purpose Inverter RX2 Series User’s Manual
dE-37
Retry monitor 7 Factor 1 to 255
Retry monitor 7 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 7 Output frequency(with sign)(LOW)
Retry monitor 7 Output current 0 to 65535
Retry monitor 7 P-N DC voltage 0 to 10000
Retry monitor 7 Inverter state
0 to 8
*1
Retry monitor 7 LAD state
0 to 5
*1
Retry monitor 7 INV control mode
0 to 11
*1
Retry monitor 7 Limit state
0 to 6
*1
Retry monitor 7 Special state
0 to 6
*1
Retry monitor 7 RUN time(HIGT)
0 to 1000000
Retry monitor 7 RUN time(LOW)
Retry monitor 7 Power ON time(HIGT)
0 to 1000000
Retry monitor 7 Power ON time(LOW)
Retry monitor 7 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 7 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 7 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
dE-38
Retry monitor 8 Factor 1 to 255
Retry monitor 8 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 8 Output frequency(with sign)(LOW)
Retry monitor 8 Output current 0 to 65535
Retry monitor 8 P-N DC voltage 0 to 10000
Retry monitor 8 Inverter state
0 to 8
*1
Retry monitor 8 LAD state
0 to 5
*1
Retry monitor 8 INV control mode
0 to 11
*1
Retry monitor 8 Limit state
0 to 6
*1
Retry monitor 8 Special state
0 to 6
*1
Retry monitor 8 RUN time(HIGT)
0 to 1000000
Retry monitor 8 RUN time(LOW)
Retry monitor 8 Power ON time(HIGT)
0 to 1000000
Retry monitor 8 Power ON time(LOW)
Retry monitor 8 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 8 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 8 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
