Omron RX2 Series User Manual

Appendices C Table of Parameters
C - 20
High-function General-purpose Inverter RX2 Series User’s Manual
*1. FA parameter indicates the current command value, and automatically displays data of the command destination that is
being adopted.
Example 1: If the command destination is the operator keypad, it can be changed using the arrow keys.
Example 2: If the command destination is the analog input Ai1, it can be changed by changing input to the terminal [Ai1].
Monitors and Parameters for Changing the Current Commands
*1
Code
Codes that
can be
changed
during
operation
Name Data range Note
FA-01 ○ Main Speed reference monitor 0.00 to 590.00 (Hz)
FA-02 ○ Sub Speed reference monitor
-590.00 to 590.00 (Hz) (for monitoring)
0.00 to 590.00 (Hz) (for setting)
FA-10 ○ Acceleration time monitor 0.00 to 3600.00 (s)
FA-12 ○ Deceleration time monitor 0.00 to 3600.00 (s)
FA-15 ○ Torque reference monitor -500.0 to 500.0 (%)
FA-16 ○ Torque bias monitor -500.0 to 500.0 (%)
FA-20 ○ Position reference monitor
When [AA121]≠10 or [AA123]≠03
-268435455 to +268435455 (pls)/
When [AA121]=10 and [AA123]=03
-1073741823 to +1073741823 (pls)
FA-30 ○ PID1 Set Value 1 monitor
0.00 to 100.00 (%)
(adjustable in [AH-04][AH-05][AH-06])
FA-32 ○ PID1 Set Value 2 monitor
FA-34 ○ PID1 Set Value 3 monitor
FA-36 ○ PID2 Set Value monitor
0.00 to 100.00 (%)
(adjustable in [AJ-04][AJ-05][AJ-06])
FA-38 ○ PID3 Set Value monitor
0.00 to 100.00 (%)
(adjustable in [AJ-24][AJ-25][AJ-26])
FA-40 ○ PID4 Set Value monitor
0.00 to 100.00 (%)
(adjustable in [AJ-44][AJ-45][AJ-46])
