Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
AC-88 ○
Deceleration time setting for
multi-speed 15
0.00 to 3600.00 (s) 0.00
AC215 -
Select method to switch to
Accel2/Decel2 Profile,
2nd-motor
00 ([2CH] terminal)/01 (Parameter setting)/
02 (Switching normal/reverse rotation)
00
AC216 ○
Accel1 to Accel2 Frequency
transition point, 2nd-motor
0.00 to 590.00 (Hz) 0.00
AC217 ○
Decel1 to Decel2 Frequency
transition point, 2nd-motor
0.00 to 590.00 (Hz) 0.00
AC220 ○
Acceleration time setting 1,
2nd-motor
0.00 to 3600.00 (s) 30.00
AC222 ○
Deceleration time setting 1,
2nd-motor
0.00 to 3600.00 (s) 30.00
AC224 ○
Acceleration time setting 2,
2nd-motor
0.00 to 3600.00 (s) 15.00
AC226 ○
Deceleration time setting 2,
2nd-motor
0.00 to 3600.00 (s) 15.00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
Ad-01 -
Torque reference input source
selection
01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)/15 (PID calculation)
07
Ad-02 ○ Torque reference value setting
-500.0 to 500.0 (%)
(Limited at a torque equivalent to 200% of inverter ND rat-
ing)
0.0
Ad-03 -
Polarity selection for torque ref-
erence
00 (As per the sign)/
01 (Follow the revolution direction)
00
Ad-04 ○
Switching time of Speed control
to Torque control
0 to 1000 (ms) 100
Ad-11 -
Torque bias input source selec-
tion
00 (Disabled)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)/15 (PID calculation)
00
Ad-12 ○ Torque bias value setting
-500.0 to 500.0 (%)
(Limited at a torque equivalent to 200% of inverter ND rat-
ing)
0.0
Ad-13 - Polarity selection for torque bias
00 (As per the sign)/
01 (Follow the revolution direction)
00
Ad-14 - Terminal [TBS] active 00 (Disabled)/01 (Enabled) 00
Ad-40 -
Input selection for speed limit at
torque control
01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
07
Ad-41 ○
Speed limit at torque control (at
Forward rotation)
0.00 to 590.00 (Hz) 0.00
Ad-42 ○
Speed limit at torque control (at
Reverse rotation)
0.00 to 590.00 (Hz) 0.00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
