Appendices C Table of Parameters
C - 40
High-function General-purpose Inverter RX2 Series User’s Manual
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
bC110 ○
Electronic thermal level setting,
1st-motor
(0.0 to 3.0)
× Inverter rated current
*1
*1. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00 (A,V). When the data of
[CF-11] Resister data selection is not set to 00 (A,V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A,V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
1.0
× Inverter
rated current
bC111 ○
Electronic thermal characteris-
tic selection, 1st-motor
00 (Reduction characteristics)/
01 (Constant torque characteristics)/
02 (Arbitrary setting)
00
*2
*2. It is a default value when Default Value Selection (Ub-02) is set to 01.
bC112 ○
Electronic thermal Subtraction
function enable, 1st-motor
00 (Disabled)/01 (Enabled) 01
bC113 ○
Electronic thermal Subtraction
time, 1st-motor
1 to 1000 (s) 600
bC-14 ○
Electronic thermal counter
memory selection at Power-off
00 (Disabled)/01 (Enabled) 01
bC120 ○
Free electronic thermal fre-
quency-1, 1st-motor
0.00 to [bC122] (Hz) 0.00
bC121 ○
Free electronic thermal cur-
rent-1, 1st-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
bC122 ○
Free electronic thermal fre-
quency-2, 1st-motor
[bC120] to [bC124] (Hz) 0.00
bC123 ○
Free electronic thermal cur-
rent-2, 1st-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
bC124 ○
Free electronic thermal fre-
quency-3, 1st-motor
[bC122] to 590.00 (Hz) 0.00
bC125 ○
Free electronic thermal cur-
rent-3, 1st-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
bC210 ○
Electronic thermal level setting,
2nd-motor
(0.0 to 3.0)
× Inverter rated current
*1
1.0
× Inverter
rated current
bC211 ○
Electronic thermal characteris-
tic selection, 2nd-motor
00 (Reduction characteristics)/
01 (Constant torque characteristics)/
02 (Arbitrary setting)
01
*2
bC212 ○
Electronic thermal Subtraction
function enable, 2nd-motor
00 (Disabled)/01 (Enabled) 01
bC213 ○
Electronic thermal Subtraction
time, 2nd-motor
1 to 1000 (s) 600
bC220 ○
Free electronic thermal fre-
quency-1, 2nd-motor
0.00 to [bC222] (Hz) 0.00
bC221 ○
Free electronic thermal cur-
rent-1, 2nd-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
bC222 ○
Free electronic thermal fre-
quency-2, 2nd-motor
[bC220] to [bC224] (Hz) 0.00
bC223 ○
Free electronic thermal cur-
rent-2, 2nd-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
bC224 ○
Free electronic thermal fre-
quency-3, 2nd-motor
[bC222] to 590.00 (Hz) 0.00
bC225 ○
Free electronic thermal cur-
rent-3, 2nd-motor
(0.0 to 3.0)
× Inverter rated current
*1
0.0
To Next Page
