2 Design
2 - 38
High-function General-purpose Inverter RX2 Series User’s Manual
* For the switching method of EMC filter, refer to the description on the bottom of
the table.
3G3RX2-A2450
R0,T0 : M4
Earth terminal: M8
Others: M8
* For the switching method of EMC filter, refer to the description on the bottom of
the table.
3G3RX2-A4450
R0,T0 : M4
Earth terminal: M8
Others: M8
Arrangement of Terminals Model
R0 T0
R
(L1)
S
(L2)
T
(L3)
U
(T1)
V
(T2)
W
(T3)
PD
(+1)
P
(+)
N
(-)
G
G
Short circuit
connector for
EMC filter
Disable
Charge lamp
(Light when electricity
turned on)
Enable
Power supply input wire
Motor output wire
PD-P short bar
R0 T0
R
(L1)
S
(L2)
T
(L3)
U
(T1)
V
(T2)
W
(T3)
PD
(+1)
P
(+)
N
(-)
G
G
Short circuit connector for
EMC filter
Disable
Charge lamp
(Light when
electricity turned on)
Enable
Power supply input wire Motor output wire
PD-P short bar
