Orolia SecureSync 2400 User Manual

Configuring a Square Wave Output
To configure one of the Square Wave Outputs:
1.
Navigate INTERFACES >OUTPUTS: Square Wave Output. The panel on the right
side of the screen displays all Sqr. Wv. Outputs and their statuses. All outputs are
numbered by signal type (e.g., 'pulse'), hence the numbering may not start with 0.
To determine which output number is allocated to which connector (J1–J4),
hover your mouse pointer over the back panel image.
Click on the INFO button next to one of the outputs to open a detailed Status
panel (the displayed settings are described below.)
2.
Click on the GEAR button to open the Edit window.
SecureSync 2400 User Manual 379
