To view the settings of
one
of the Alarm Outputs or CTCSS Outputs, go to its Status win-
dow. For instructions, see: "Viewing Input/Output Configuration Settings" on page334.
The Web UI list entry for this card is named: Simulcast.
Note: Alarm Output 0 through Alarm Output 3 are reserved by
SecureSync. Numbering for alarm outputs from the option card will begin
at Alarm 4, which is available on the DB-9 output, while Alarms 5 and 6 are
assigned to the RJ-12 connector.
Figure 5-28: Simulcast Alarm Output Status window
CTCSS Outputs: Edit Window
To configure a CTCSS output, go to its Edit window. For instructions, see: "Configuring
Option Card Inputs/Outputs" on page336.
The Web UI list entry for this card is named: Simulcast.
The Edit window allows the configuration of the following settings:
SecureSync 2400 User Manual 385
APPENDIX
