Signal Type: Allows selection of the desired signal type. Available options include:
Disabled
CTCSS 1/3 Tones
CTCSS 1/10 Tones
Data Clocks
1PPS
Signal Output:
CTCSS 1/3 Tones (see also: "CTCSS exact (1/3 Hz) tones" on page388)
CTCSS 1/10 Tones (see also: "CTCSS exact (1/10 Hz) tones" on page389)
Data Clocks (see also: "Data Clock Signals" on page389)
1PPS (see also: "1PPS Duty Cycle" on page389)
Offset: Value in nanoseconds that can be used to adjust for cable delays or laten-
cies.
Signature Control: Controls when the output will be present. For more inform-
ation, see "Signature Control" on page161.
819x Option 17 Mapping
To replicate settings used in Series 819x devices, use the following information to con-
figure option card no. 1204-14 for compatible CTCSS operation:
DB-9 Output Index 0: Set to desired CTCSS 1/10 or CTCSS 1/3 tone
DB-9 Output Index 1: Set to 18 kHz Data Clock
DB-9 Output Index 2: Set to desired CTCSS 1/10 or CTCSS 1/3 tone.
Alarm Outputs: Edit Window
To configure one of the ALARM Outputs, go to its Edit window. For instructions, see:
"Configuring Option Card Inputs/Outputs" on page336.
The Web UI list entry for this card is named: Simulcast.
386 SecureSync 2400 User Manual
