Pin Assignments
J1 Pin No. Function
1 IRIG Output 1 +
2 IRIG Output 1 –
3 GND
4 IRIG Output 2 +
5 IRIG Output 2 –
6 IRIG Output 3 +
7 IRIG Output 3 –
8 GND
9 IRIG Output 4 +
10 IRIG Output 4 –
Table 5-14:
1204-22 terminal block pin-out
IRIG Output: Viewing Signal State
To quickly view if an IRIG output is enabled or disabled, go to the option card’s Status Sum-
mary panel. For instructions, see: "Viewing an Input/Output Signal State" on page337.
IRIG Output: Edit Window
To configure an IRIG Output, go to its Edit window. For instructions, see: "Configuring
Option Card Inputs/Outputs" on page336.
The Web UI list entries for these option cards are: IRIG Out BNC, IRIG Out Fiber, IRIG
Out RS-485.
