Pin No. Signal Function
2 SERIALTX_RS485- - RS-485 data output
3 GND Ground
4 PPS_OUT_RS485+ + 1PPS output
5 PPS_OUT_RS485- - 1PPS output
6 SERIALRX_RS485+ + RS-485 data input
7 SERIALRX_RS485- - RS-485 data input
8 GND Ground
9 PPS_IN_RS485+ + 1PPS input
10 (right) PPS_IN _RS485- - 1PPS input
ASCII Time Code Input: Edit Window
To configure the ASCII Input (also referred to as ‘Reference’), go to its Edit window. For
instructions, see: "Configuring Option Card Inputs/Outputs" on page336.
The Web UI list entries for this card are: ASCII TIMECODE RS-232 and ASCII TIMECODE
RS-485.
