Figure 5-54: Model 1204-0F option card rear plate

Terminal block pin-out, alarm relay out

PIN SIGNAL

1 GND

2 Relay 0 NO

3 Relay 0 NC

4 Relay 0 COMMON

5 Relay 1 NO

6 Relay 1 NC

7 Relay 1 COMMON

8 Relay 2 NO

9 Relay 2 NC

10 Relay 2 COMMON

Operation of the Alarm Relay Card
