Orolia SecureSync 2400 User Manual

Note: If you have only one input or output of any type, NetClock will number
that input or output 0. Additional inputs or outputs will be numbered 1 or
above.
The IRIGoutput Edit window offers the following configuration fields:
Signature Control: Used to control when the IRIG modulation will be present. This
function allows the modulation to stop under certain conditions;see also "Signature
Control" on page161.
Format: Defines the desired IRIG output formatting. Available options include: IRIG
A, B, G, NASA-36, IRIG E (100Hz or 1kHz)
Modulation: Changes the type of output signal modulation:
IRIG AM is an amplitude modulated output. The amplitude of the output is
determined by the value entered in the “Amplitude” field.
IRIG DCLS is a TTL modulated output.
SecureSync 2400 User Manual 497
