Parity: Configures the parity checking of the output port.
Stop Bits: Defines the number of Stop Bits for the output.
Event Broadcast Output: Status Window
To view the current settings of the Event Broadcast Output, go to its Status window. For
instructions, see: "Viewing Input/Output Configuration Settings" on page334.
The Web UI list entry for this card is: Event Broadcast.
The Status window displays the following settings:
Signature Control: Signature Control controls when messages will be broadcast in
response to events on the Event Input (J2) port when events are enabled and the
card is in “broadcast” mode. (Events are still queued even if they are not broadcast,
and are transmitted once the signature control conditions permit.) For more inform-
ation on Signature Control, see "Signature Control" on page161.
Format: The format of the message to be output. Refer to "Event Broadcast Time
Code Formats" on page511 for a description of all of the available formats.
The Event Broadcast card only supports two formats (Event Broadcast Format 0
and Event Broadcast Format 1), and only supports the output of one message per
event. If format is set to “None”, no messages will be queued in the Message Buffer.
Output Mode: When the output data will be provided. Available Mode selections are
as follows:
Broadcast—Event Messages are automatically broadcast when they are cre-
ated by an event. If a new event happens while an older message is being
broadcast, the new message will be queued in a “First-in, First-out” manner.
When the message has finished, the next message out of the queue will be
broadcast.
SecureSync 2400 User Manual 509
