Plockmatic BM3050 system 27 August 2019 3. Repairs and adjustments (REP and ADJ)
3-118
REP 11.23 Stop Gate
Parts List 10.7
1. Set up the Square Folder to Mode 1.
2. Run 6 sheet booklets of 80 gsm (20lb bond), from the Copier.
3. Check appearance of booklets according to pictures below.
If results are not good, proceed to BQ 12.
Not GoodGoodNot Good
To Next Page
