Plockmatic BM3050 system 27 August 2019 4. Troubleshooting (RAP)
4-229
Square Folder Transport RAP
This RAP is for troubleshooting the Square Folder Transport.
You should have been re-directed to this RAP from another Status indicator RAP.
Procedure
Check Sensor SQF-Q5 (PL 10.4) according to GP4.
Is Sensor Q5 working correctly?
Y N
Go to SQF-014.
Check Sensor SQF-Q6 (PL 10.7) according to GP4.
The sensor Q6 is working correctly
Y N
Go to SQF-015.
Check Sensor SQF-Q7 (PL 10.5) according to GP4.
Is Sensor SQF-Q7 working correctly?
Y N
Go to SQF-016.
Check Motor SQF-M1 (PL 10.7), SQF-SOL1 (PL 10.3), SQF-SOL 3 (PL 10.3) , SQF-SOL 2
(PL 10.4) and SQF-SOL4 (PL 10.4) according to GP4.
Are the Upper and Lower Transport belts working correctly?
Y N
Check for mechanical bindings, broken, missing or loose parts.
Check that both Springs (PL 10.3) on the upper Transport belts are in the upper position.
Is the Square Folder Transport working correctly?
Y N
Clean the transport belts.
Return to the previous RAP.
SQF-501 Stacker Full
Fault code indicates that the Belt Stacker is full.
Procedure
Empty Belt Stacker and press Done on the UI.
Note: This function can also be turned off under the Tools menu on the UI.
Clamp RAP
This RAP is for troubleshooting the Clamp motor.
You should have been re-directed to this RAP from another Status indicator RAP.
Procedure
Check Motor SQF-M3 (PL 10.5) according to GP4.
Are the clamps working correctly?
Y N
Check for mechanical bindings, broken, missing or loose parts.
Return to the previous RAP
Square Folder Stop Gate RAP
This RAP is for troubelshooting the Square Folder Stop Gate.
You should have been re-directed to this RAP from another Status indicator RAP.
Procedure
Check Motor SQF-M2 (PL 10.7) according to GP4.
The Stop Gate is working correctly
Y N
Check for mechanical bindings, broken, missing or loose parts.
Return to the previous RAP.
