Plockmatic BM3050 system 27 August 2019 5. Service tables (GP)
5-17
GP 7 Dead Cycle
Purpose
This procedure is a modied machine cycle.
All functions in the machine are run such as motors and solenoids.
The program is basically made for factory testing,
but can be of some use when trouble shooting.
Procedure
Warning!
Changing NVM values can jeopardize the way the machine operates considerably.
Be sure that changing the NVM value is the correct solution before doing so.
If changes are made which cause the unit to operate incorrectly,
perform the NVM reset procedure (GP 20).
Running Dead Cycling (free run)
1. Select Module:
2. Remove the two stapler heads.
3. Go to Dead Cycle.
4. Press START to start the dead cycling.
5. Press STOP to stop the dead cycling.
GP 8 Not in use
GP 9 Not in use
