Plockmatic BM500 - Drive Motor (M1) Transmission RAP

Plockmatic BM3050 system 27 August 2019 4. Troubleshooting (RAP)
4-91
Drive Motor (M1) Transmission RAP
This RAP is for troubleshooting the Drive Motor (M1) Transmission.
Initial Actions
• Enter Service (GP 1)
• Check motor M1 (PL 12.5) according to GP4.
Procedure
• Switch on Drive Motor (M1).
• Check that all Drive Motor (M1) Transmission Components are moving
as indicated in Figures (1, 2, 3).
All Components are moving as indicated?
Y N
Fix problem.
Return to the RAP that directed you here.
Figure 1 Drive Motor (M1) Transmission Components
Figure 2 Drive Motor (M1) Transmission Components
