Plockmatic BM3050 system 27 August 2019 1. Installation Procedure
1-65
1.14.5 CHECKING THE SQUARE FOLD
WARNING:
To avoid hazardous situations, please read and follow the safety informa-
tion in section 1.3 in this manual.
1. In the UI, press [Book Fold].
2. Press [Auto].
3. Press [OK].
4. Press [Crease].
5. Press [AUTO]
6. Press [OK]
Booklet maker setup should read:
Input Sheet Size: SRA3 or 12x18”
Face Trim: 0,0mm or 0.000”
Bleed Trim: 11,5mm or 0.500”
Staple: ON
Cover: OFF
Book Fold: Status: ON, Mode: Auto
Fold position: AUTO
Crease: Status: AUTO, Offset: 0,0mm/0.000”
7. Using 80 gsm/20 lb Bond sheets, send ve sets of 2 sheet
SRA3/12x18” (2 sheets of SRA3/12x18” equals a booklet containing 8
pages) to the Booklet Maker system.
8. Check that the booklet cover do have a crease and that the booklets
not have a Book Folded spine.
9. Send ve sets of 10 sheet SRA3/12x18” (10 sheets of SRA3/12x18”
equals a booklet containing 40 pages) to the Booklet Maker system.
10. Check that the booklet cover does not have a crease and that the
booklets have a Book Folded spine.
1.14.6 CHECKING THE TRIMMER
WARNING:
To avoid hazardous situations, please read and follow the safety informa-
tion in section 1.3 in this manual.
11. In the UI, press [Finished Booklet Size].
12. Press [Edit].
13. Press [Clear] to clear length setting.
14. Set length to 210,0mm/8.500” and press [OK]. You can see that you
will receive booklets 297mm/11” tall and 210mm/8.5” wide.
15. Press [OK].
You can now see that the SRA3/12x11” sheets will have a Bleed Trim
of 11,5mm/0.500” on each side and Face Trim of 15,0mm/0.500.
Booklet maker setup should read:
Input Sheet Size: SRA3 or 12x18”
Face Trim: 15,0mm or 0.500”
Bleed Trim: 11,5mm or 0.500”
Staple: ON
Cover: OFF
Book Fold: Status: ON, Mode: Auto
Fold position: AUTO
Crease: Status: ON, Offset: 0,0mm/0.000”
16. Using 80 gsm/20 lb Bond sheets, send ve sets of 2 sheet
SRA3/12x18” (2 sheets of SRA3/12x18” equals a booklet containing 8
pages) to the Booklet Maker system.
17. Check that the bookets are trimmed and 210,0mm/8.500” wide.
