Plockmatic BM500 - Square Folder; Trimmer

Plockmatic BM3050 system 27 August 2019 2. Preventive Maintenance (PM)
2-4
SQUARE FOLDER
Note: Square Folder set counts are based on 6 sheets / set.
Check point Instruction Part Name Spare
Part No.
Qty Service
manual
Spare Parts
manual
Maintenance
Interval
Paper path Use a vacuum cleaner, towel and brushes to
clean the machine from paper dust
125K
Sensors Use compressed air or a brush to clean sen-
sors
125K
Upper transport belts (x2) Use lm remover to clean belts REP 11.19 125K
Lower transport belts (x2) Use lm remover to clean belts REP 11.20 125K
Pressure Roller Inspect Timing Belt. for tension and wear. REP 11.19 125K
Lower and upper clamp Silicon grease on clamps against guides REP 11.22 125K
Plastic guides Silicon grease on guides against clamps REP 11.22 125K
Transport belt kit, upper
& lower, 2+2 belts
Replace Transport belt 488x32
UU 20U
17232 2 REP 11.17,
11.20
PL10.3, It.3 2M
Clamp motor BF-M3 Replace Motor Wevin with con-
nector
782044 1 REP 11.8 PL10.5, It.5 3M
Roller motor BF-M4, with
Harness
Replace Motor, roller 172052 1 REP 11.9 PL10.6, It.4 3M
Bushing, Clamp linkage Replace Sintered bearing
8/12x8-16x2
24653 4 REP 11.22 PL10.2, It.10 3M
TRIMMER
Note: Trimmer set counts are based on 4 sheets / set and one trim stroke / booklet..
Check point Instruction Part Name Spare
Part No.
Qty Service
manual
Spare Parts
manual
Maintenance
Interval
Paper Path Use a vacuum cleaner, towel and brushes to
clean the machine from paper dust
125K
Sensors Use compressed air or a brush to clean sen-
sors
125K
Infeed belts (2x4) Use lm remover to clean belts REP 10.27 125K
Lower Exit belts (x2) Use lm remover to clean belts REP 10.22 125K
Upper Exit belts (x2) Use lm remover to clean belts REP 10.23 125K
Trim Knife Inspect trim result; 2 and 50 sheets REP 10.16,
10.17
125K
