Plockmatic BM500 - Registration Solenoid SOL5 Trigger Sensor CT-Q10 Activated too Long

Plockmatic BM3050 system 27 August 2019 4. Troubleshooting (RAP)
4-39
CT-206 Registration Solenoid SOL5 Trigger Sensor
CT-Q10 activated too long
Fault code indicates that at ”initialization” or during a run,
the paper Registration Solenoid SOL5 Trigger Sensor CT-Q10,
was blocked exceeding timeout.
Initial Actions
• Ensure all connectors are properly connected.
• Ensure that the paper Registration Solenoid SOL5 Trigger Sensor
CT-Q10 (PL 12.20) is clean.
• Check that there are no obstructions in the paper path.
• Checkthatalljamclearancebafescloseproperly
Procedure
Enter Service (GP 1).
Check registration sensor Q10 according to GP4.
Registration Solenoid SOL5 Trigger Sensor (Q10) works OK.
Y N
Go to Registration Solenoid SOL5 Trigger Sensor (Q10) RAP.
Check drive motor M1 according to GP4.
Drive Motor (M1) works OK.
Y N
Go to Drive Motor (M1) RAP.
Check rotator motor M3 according to GP4.
Rotator Motor (M3) works OK.
Y N
Go to Rotator Motor (M3) RAP.
Go to Drive Motor (M1) RAP and Rotator Motor (M3) RAP,
and check that transportation drive and idler rollers are in good working order.
Drive and Idler Rollers are OK.
Y N
Fix problem
Check rotator disengage solenoid SOL2 according to GP4.
Rotator Disengage Solenoid (SOL2) and mechanism works OK.
Y N
Go to Rotator Disengage Solenoid (SOL2) RAP
Check rotator disengage solenoid SOL2 according to GP4.
Rotator Disengage Solenoid (SOL2) and mechanism works OK.
Y N
Go to Rotator Disengage Solenoid (SOL2) RAP
Ensure that the CST is correctly installed.
CheckrstforpaperpathmisalignmentandInterfaceCable.
Installation is OK.
N Re-install CST.
