Plockmatic BM3050 system 27 August 2019 2. Preventive Maintenance (PM)
2-8
AF602 (CONTINUED)
Sheet Count Range: 6,5M - 12M Total Sheet Count
Check point Instructions SP Manual 6,5M 7M 7,5M 8M 8,5M 9M 9,5M 10M 10,5M 11M 11,5M 12M
Paper path etc
Use compressed air, towel and brushes to clean the
machine from paper dust.
N/A x x x x x x x x x x x x
Outfeed sensor (Q303) Use compressed air to clean sensor. PL 3.1a x x x x x x x x x x x x
Optical DSD sensors
(Q101/Q201)
Clean with moist cloth and calibrate sensor. PL 6.3 x x x x x x x x x x x x
Ultrasonic DSD sensors
(Q102/Q202)
Clean with moist cloth and calibrate sensor. PL 6.3 x x x x x x x x x x x x
Feed rollers
Use rubber reactivator alcohol uid to clean feed rollers.
Check for wear, if worn replace.
PL 2.3a/b x x x x x x x x x x x x
Separator pads
Use rubber reactivator alcohol uid to clean separator
pads. If worn, replace both pads.
PL 2.3a/b x x x x x x x x x x x x
Drive shaft
Use rubber reactivator alcohol uid to clean feed rollers.
Check for wear, if worn replace.
PL 3.0 x x x x x x x x x x x x
Drive shaft
Use rubber reactivator alcohol uid to clean feed rollers.
Check for wear, if worn replace.
PL 3.1b x x
x x x x x x x x x x
Timing belt 10T5/1800 (M301) Replace PL 4.0 x x
Timing belt 10T5/1315 (M301) Replace PL 4.0 x x
Timing belt 10T5/2500 (M201) Replace PL 2.0 x x
Timing belt 10T5/2500 (M101) Replace PL 2.0 x x
Clutch 24v (SOL101/SOL201) Replace PL 2.3a x x
Timing belt 10T5/330 Replace PL 2.3a/b x x
Timing wheel Replace PL 2.3 a/b x x
Timing wheel, slotted Replace PL 2.3a x x
Timing belt 8T5/100 Replace PL 2.3a/b x x
Solenoid Bin Lock
(SOL102/SOL202)
Replace PL 2.0 x
Interlock switch x3 Replace PL 2.0 / 3.0 x
Blower Fan x8 Replace PL 2.1a/b x
Coupling shaft Replace PL 4.0 x
