Plockmatic BM3050 system 27 August 2019 2. Preventive Maintenance (PM)
2-10
VF602 (CONTINUED)
Sheet Count Range: 6,5M - 12M Total Sheet Count
Check point Instructions SP Manual 6,5M 7M 7,5M 8M 8,5M 9M 9,5M 10M 10,5M 11M 11,5M 12M
Paper path etc
Use compressed air, towel and brushes to clean the machine
from paper dust.
N/A x x x x x x x x x x x x
Exit feed sensor (Q303) Use compressed air to clean sensor. PL 3.1A x x x x x x x x x x x x
Optical DSD sensors
(Q101/201)
Clean with moist cloth and calibrate sensor. PL 2.3 x x x x x x x x x x x x
Ultrasonic DSD sensors
(Q102/Q202)
Clean with moist cloth and calibrate sensor. PL 2.3 x x x x x x x x x x x x
Separator pads
Use rubber reactivator alcohol uid to clean separator pads.
Always replace both separator pads.
PL 2.4 x x x x x x x x x x x x
Drive shaft
Use rubber reactivator alcohol uid to clean feed rollers.
Replace if worn.
PL 3.0 x x x x x x x x x x x x
Drive shaft, exit area
Use rubber reactivator alcohol uid to clean feed rollers.
Replace if worn.
PL 3.1A x x x x x x x x x x x x
Timing belt 10T5/1800 (M301) Replace PL 4.0 x x
Timing belt 10T5/1315 (M301)
Replace PL 4.0 x x
Timing belt 10T5/2500 (M201) Replace PL 2.0 x x
Timing belt 10T5/2500 (M101) Replace PL 2.0 x x
Clutch 24v (SOL101/201) Replace PL 2.3 x x
Clutch 24v (SOL104/204) Replace PL 2.3 x x
Timing belt 10T5/330, Tray,
Feeder
Replace PL 2.3 x x
Solenoid Bin Lock
(SOL102/SOL202)
Replace PL 2.3 x
Interlock switches Replace PL 2.0, 3.0 x
Blower Fan x12 Replace PL 2.1, 2.3 x
Coupling shaft x2 Replace PL 4.0 x
Solenoid Vacuum Release
(SOL103/203)
Replace PL2.3 x x
Suction Belts (Feeder
Assembly)
Use rubber reactivator alcohol uid to clean suction belts.
Replace if worn.
PL 2.3 x x
