PREVOST X3-45 COMMUTER User Manual

SECTION 05: COOLING SYSTEM
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
3
1. TORQUE TABLES
1.1 HOSE CLAMPS
05179_1
HOSE CLAMPS
No DESCRIPTION TORQUE
1 Hose clamps - coolant lines (2.5 in O.D) 30 lb-in (3.39 Nm)
2 Constant-torque hose clamps - charge air cooler (CAC) 4.5-5.5 lb-ft (6.1-7.46 Nm)
3 Intake elbow - V-clamps (both) 4.5-6 lb-ft (6.1-8.13 Nm)
4 Screw, CAC air temperature sensor 5.3-6.5 lb-ft (7-9 Nm)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
