PREVOST X3-45 COMMUTER User Manual

Mi14-01E Page 36 / 38 Rev: Oct 2021
3.2.1 SECOND LIFT
1.
Perform the first lift as instructed in
paragraph 3.2 if not already done.
2. Retract the tow truck stinger arm.
3. Pre-
adjust spacing between the axle fork
holders to 43 inches.
Figure 66
4. Install either long or short axle forks into fork
holders.
or
TALL REGULAR
5. Deploy the tow truck stinger arm. Place the
axle forks
under the rear tow eyes if
equipped or under the side-members (Figure
67 & Figure 68).
Place the forks in a transversal position i.e.
perpendicularly to the side-members (Figure
68).
Figure 67: REAR TOW EYES ON SIDE-MEMBERS LOCATED
UNDER ENGINE CRADLE SUPPORT RAILS

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
