PREVOST X3-45 COMMUTER User Manual

Mi14-01E Page 35 / 38 Rev: Oct 2021
6. Unload or raise the tag axle to prevent it from
hanging unsupported. To do so, open the front
service compartment located on street side and
move the tag axle air valve lever forward as
shown on figure 57.
Figure 64
7. Lift the rear end of the bus high enough to allow
installation of tow cans or blocks underneath the
drive axle wheels (Figure 65).
8. With precaution, lower the rear of bus.
Figure 65

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
