SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
51
10.4 ZONE 4
FIGURE 83: ZONE 4
10.4.1 Rear Fender
Rear fenders are hinged for maintenance on
brakes and suspension. Each rear fender panel
has two mechanical spring loaded holding
devices fixing it to the vehicle’s structure.
FIGURE 84: LEFT REAR FENDER LATCHES
To lift a rear fender:
1. Push rod sideways on latch A and B
(image above);
2. Pull the secondary latch and then lift the
fender.
NOTE
The vehicle is equipped with a secondary lock.
Pull the handle to disengage the lock.
FIGURE 85: SECONDARY LATCH

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
