SECTION 01 : ENGINE
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual Section 01 revised Jan 2021
21
2.7 POWER PLANT ASSY. INSTALLATION
To install a power plant assembly, follow the
same procedure as in "Power Plant Assembly
Removal" except in reverse order, then proceed
with the following:
1. Torque the power plant cradle mounting
bolts.
TORQUE: 190 lb-ft (258 Nm)
2. Reposition the oil filter as shown in Figure
17.
FIGURE 17: NORMAL OIL COOLER POSIT ION
3. Reinstall compressor mounting bolts (4).
4. Reinstall both screws ‘’A’’.
5. Reinstall the A/C compressor clutch
assembly.
6. Reinstall both screws ‘’A’’.
7. Reinstall the A/C compressor clutch
assembly.
FIGURE 18: COMPRESSOR MOUNTING BOLTS

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
