SECTION 14: STEERING
36
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
17 SPECIFICATIONS
Power Steering Gear
Make ..................................................................................... ZF/ROBERT BOSCH-SERVOCOMTRONIC
Type ................................................................................................................................ Speed Sensitive
F.E.W.......................................................................................................................16,600 lbs (7 545 kg)
Pressure rating ............................................................................................................ 2,175 psi (150 Bar)
Gear ratio (center) ......................................................................................................................... 22.2 : 1
Gear ratio (extremities) .................................................................................................................. 26.2 : 1
Minimum pump flow for 1.5 hwt/sec .............................................................................. 4.22 gpm (16 lpm)
Power steering tank
Oil capacity ................................................................................................................ 1.6 US qts (3.17 pt)
Steering Stabilizer Cylinder (Damper)
Extended length ..................................................................................................................... 32.73±0.12"
Collapsed length..................................................................................................................... 20.26±0.12"
Stroke..................................................................................................................................... 12.47±0.12"
Front I-Beam Axle
Make ................................................................................................................. DANA SPICER EUROPE
Model ............................................................................................................................................... S84U
Front Track ........................................................................................................... 84.4 inches (2 145 mm)
Rated load capacity ..................................................................................................16,500 lbs (7 500 kg)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
