PREVOST X3-45 COMMUTER User Manual

SECTION 00 : GENERAL INFORMATION
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
11
4.2.2 Metric
TYPE DESCRIPTION THREAD GRADE
RECOMMENDED
TORQUE, ±10%
lb-ft (dry) otherwise
specified
Tolerance: ±10%
METRIC M6 X 1 nut 8 / screw 8.8 7 lb-ft (10 Nm)
METRIC M6 X 1 nut 10 / screw 10.9 10 lb-ft (13 Nm)
METRIC M6 X 1 nut 12 / screw 12.9 12 lb-ft (16 Nm)
METRIC M8 X 1.25 nut 8 / screw 8.8 17 lb-ft (23 Nm)
METRIC M8 X 1.25 nut 10 / screw 10.9 24 lb-ft (32 Nm)
METRIC M8 X 1.25 nut 12 / screw 12.9 28 lb-ft (38 Nm)
METRIC M10 X 1.5 nut 8 / screw 8.8 35 lb-ft (47 Nm)
METRIC M10 X 1.5 nut 10 / screw 10.9 48 lb-ft (65 Nm)
METRIC M10 X 1.5 nut 12 / screw 12.9 56 lb-ft (76 Nm)
METRIC M12 X 1.75 nut 8 / screw 8.8 59 lb-ft (80 Nm)
METRIC M12 X 1.75 nut 10 / screw 10.9 82 lb-ft (111 Nm)
METRIC M12 X 1.75 nut 12 / screw 12.9 96 lb-ft (130 Nm)
METRIC M14 X 2 nut 8 / screw 8.8 94 lb-ft (128 Nm)
METRIC M14 X 2 nut 10 / screw 10.9 130 lb-ft (176 Nm)
METRIC M14 X 2 nut 12 / screw 12.9 152 lb-ft (206 Nm)
METRIC M16 X 2 nut 8 / screw 8.8 143 lb-ft (194 Nm)
METRIC M16 X 2 nut 10 / screw 10.9 198 lb-ft (268 Nm)
METRIC M16 X 2 nut 12 / screw 12.9 231 lb-ft (314 Nm)
METRIC M16 X 1.5 nut 10 / screw 10.9 206 lb-ft (279 Nm)
METRIC M16 X 1.5 nut 12 / screw 12.9 241 lb-ft (326 Nm)
METRIC M20 X 2.5 nut 8 / screw 8.8 280 lb-ft (379 Nm)
METRIC M20 X 2.5 nut 10 / screw 10.9 387 lb-ft (524 Nm)
METRIC M20 X 2.5 nut 12 / screw 12.9 452 lb-ft (613 Nm)
METRIC M20 X 1.5 nut 10 / screw 10.9 415 lb-ft (563 Nm)
METRIC M20 X 1.5 nut 12 / screw 12.9 485 lb-ft (658 Nm)
METRIC M22 X 2.5 nut 8 / screw 8.8 373 lb-ft (506 Nm)
METRIC M22 X 2.5 nut 10 / screw 10.9 516 lb-ft (700 Nm)
METRIC M22 X 2.5 nut 12 / screw 12.9 604 lb-ft (818 Nm)
METRIC M24 X 3 nut 8 / screw 8.8 481 lb-ft (652 Nm)
METRIC M24 X 3 nut 10 / screw 10.9 665 lb-ft (902 Nm)
METRIC M24 X 3 nut 12 / screw 12.9 777 lb-ft (1054 Nm)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
