5.8 TEMPERATURES & PRESSURE
CHART
R134a VAPOR-PRESSURE
TEMPERATURE PRESSURE
F
C
psi kPa
-100 -73.3 27.8 191.7
-90 -67.8 26.9 185.5
-80 -62.2 25.6 176.5
-70 -56.7 23.8 164.1
-60 -51.1 21.5 148.2
-50 -45.6 18.5 127.6
-40 -40.0 14.7 101.4
-30 -34.4 9.8 67.6
-10 -23 1.8 12.4
0 -18 6.3 43.4
10 -12 11.6 80
20 -7 18.0 124.1
30 -1 25.6 176.5
40 4 34.5 237.9
50 10 44.9 309.6
60 16 56.9 392.3
70 21.1 70.7 487.5
80 27 86.4 595.7
90 32.2 104.2 718.5
110 43.3 146.8 1012.2
120 49 171.9 1185.3
130 54.4 199.8 1377.6
150 65.6 264.4 1823.0
170 76.7 342.0 2358.1
180 82.2 385.9 2660.8
190 87.8 433.6 2989.7
200 93.3 485.0 3344.1
210 98.9 540.3 3725.4
5.9 LEAK TESTING
A leak can be identified by the presence of oil
residue on the components.
The preferred method for leak testing is to
replace refrigerant with pressurized nitrogen and
spaying soap on suspected leaks. Any bubbles
appearing would indicate a leak.
Additional possible methods include electronic
leak detectors and fluorescent dye and UV light.
